Makita ELM3320 User Manual

10 ENGLISH
The lines on both sides of the main body are guidelines
to mowing width. Using the lines as guidelines, mow in
strips. Overlap by one half to one third the previous strip
to mow the lawn evenly.
12
33
►1. Mowing width 2. Overlapping area 3. Line
Change the mowing direction each time to prevent the
grassgrainpatternfromforminginjustonedirection.
Periodically check the grass basket for mowed grass.
Empty the basket before it becomes full. Before every
periodic check, be sure to stop the machine.
NOTE: Using the mower with the grass basket full
prevents smooth blade rotation and places an extra
load on the motor, which may cause a breakdown.
Mowing a long-grass lawn
Do not try to cut long grass all at once. Instead, mow
the lawn in steps. Leave a day or two between mowings
until the lawn becomes evenly short.
NOTE: Mowing long grass to a short length all at
once may cause the grass to die. The cut grass may
also block up inside of the mower body.
Edge mowing
When mowing at the edge, be sure to move the
machine along the edge.
MAINTENANCE
WARNING: Before performing the mainte-
nance, unplug the extension cord from the power
supply, and conrm that the blades have come to
a complete halt.
CAUTION: When performing the mainte-
nance, always wear gloves.
To maintain product SAFETY and RELIABILITY,
repairs,anyothermaintenanceoradjustmentshould
be performed by Makita Authorized or Factory Service
Centers, always using Makita replacement parts.

Makita ELM3320 Specifications

General

Type	Walk behind lawn mower
Easy to use	Yes
Cutting width	33 mm
Grass catcher	No
Product color	Black, Turquoise
Maximum lawn area	400 m²
Mulching function	-
Handle(s) features	Adjustable
Maximum cutting height	55 mm
Minimum cutting height	20 mm
Number of height positions	3
Power source	AC

Weight and Dimensions

Depth	1230 mm
Width	380 mm
Height	1110 mm
