Makita XCU11 User Manual

8 ENGLISH
FUNCTIONAL
DESCRIPTION
CAUTION: Always be sure that the tool is
VZLWFKHGRႇDQGWKHEDWWHU\FDUWULGJHLVUHPRYHG
before adjusting or checking function on the tool.
Installing or removing battery
cartridge
CAUTION: $OZD\VVZLWFKRႇWKHWRROEHIRUH
installing or removing of the battery cartridge.
CAUTION: Hold the tool and the battery car-
WULGJH¿UPO\ZKHQLQVWDOOLQJRUUHPRYLQJEDWWHU\
cartridge. Failure to hold the tool and the battery
FDUWULGJH¿UPO\PD\FDXVHWKHPWRVOLSRႇ\RXUKDQGV
and result in damage to the tool and battery cartridge
DQGDSHUVRQDOLQMXU\
1
2
3
Fig.3
Ź1. Red indicator 2. Button 3. Battery cartridge
To remove the battery cartridge, slide it from the tool
while sliding the button on the front of the cartridge.
To install the battery cartridge, align the tongue on the
battery cartridge with the groove in the housing and slip
it into place. Insert it all the way until it locks in place
with a little click. If you can see the red indicator as
VKRZQLQWKH¿JXUHLWLVQRWORFNHGFRPSOHWHO\
CAUTION: Always install the battery cartridge
fully until the red indicator cannot be seen. If not,
LWPD\DFFLGHQWDOO\IDOORXWRIWKHWRROFDXVLQJLQMXU\WR
you or someone around you.
CAUTION: Do not install the battery cartridge
forcibly. If the cartridge does not slide in easily, it is
not being inserted correctly.
Indicating the remaining battery capacity
Only for battery cartridges with the indicator
1
2
Fig.4
Ź1. Indicator lamps 2. Check button
Press the check button on the battery cartridge to indi-
cate the remaining battery capacity. The indicator lamps
light up for a few seconds.
Indicator lamps Remaining
capacity
Lighted 2ႇ Blinking
75% to 100%
50% to 75%
25% to 50%
0% to 25%
Charge the
battery.
The battery
may have
malfunctioned.
NOTE: Depending on the conditions of use and the
DPELHQWWHPSHUDWXUHWKHLQGLFDWLRQPD\GLႇHUVOLJKWO\
from the actual capacity.
NOTE:7KH¿UVWIDUOHIWLQGLFDWRUODPSZLOOEOLQNZKHQ
the battery protection system works.
Tool / battery protection system
The tool is equipped with a tool/battery protection sys-
WHP7KLVV\VWHPDXWRPDWLFDOO\FXWVRႇSRZHUWRWKH
motor to extend tool and battery life. The tool will auto-
matically stop during operation if the tool or battery is
placed under one of the following conditions:
Overload protection
When the tool or battery is operated in a manner that
causes it to draw an abnormally high current, the tool
DXWRPDWLFDOO\VWRSV,QWKLVVLWXDWLRQWXUQWKHWRRORႇ
and stop the application that caused the tool to become
overloaded. Then turn the tool on to restart.
