Operation
51
Carefully read the Operating Instructions before starting any work!
This is especially valid for the chapter on General Safety Instructions
and the safety instructions in each of the chapters.
7.3.4 Checking Engine Oil Level
NOTE!
Check the oil level when the engine is horizontal and only after at least 20 minutes have
passed since the engine was switched off.
1. Pull out oil dipstick (1).
2. Wipe off oil dipstick (1) with a lint-free, clean
cloth.
3. Reinsert the oil dipstick (1) all the way.
4. Pull out oil dipstick (1) again and check oil level.
The oil level should be between both of the marks
on the dipstick and should never drop below the
lower mark.
5. Reinsert the oil dipstick (1) all the way.
If the oil level is too low, refill with new oil.
1
MIN
MAX
