SERVICING SCHEDULE
(1): MANDATORY 500 HOUR OR 6 MONTH SERVICE
This service must be carried out after approximately the first 500 hours of operation or within the 6 months following the start-up of the machine
(whichever occurs first).
A = ADJUST, C = CHECK, G = GREASE, N = CLEAN,
P = BLEED, R = REPLACE, V = DRAIN
PAGE
(1)
DAILY OR EVERY 10
HOURS SERVICE
EVERY 50 HOURS
SERVICE
EVERY 250 HOURS
SERVICE
EVERY 500 HOURS
SERVICE OR 6
MONTHS
EVERY 1000 HOURS
SERVICE OR 1 YEAR
EVERY 2000 HOURS
SERVICE OR 2
YEARS
EVERY 4000 HOURS
SERVICE
OCCASIONALLY
I.C. ENGINE
I.C. engine oil level
3-12 C C <<< <<< <<< <<< <<< <<<
Cooling liquid level
3-12 C C <<< <<< <<< <<< <<< <<<
Fuel level
3-12 C C <<< <<< <<< <<< <<< <<<
Fuel pre-filter
3-12 C C <<< <<< <<< <<< <<< <<<
Cyclonic pre-filter (OPTION)
3-13 N N <<< <<< <<< <<< <<< <<<
Dry air filter cartridge
3-16/25 R N <<< R <<< <<< <<<
Radiator core
3-16 N N <<< <<< <<< <<< <<<
Condenser core (OPTION Air conditioning)
3-16 C/N C/N <<< <<< <<< <<< <<<
Alternator belt tension
3-20 C/A C/A <<< <<< <<< <<<
Compressor belt tension (OPTION Air conditioning)
3-20 C/A C/A <<< <<< <<< <<<
Alternator belt tension (air conditioning OPTION)
3-22 C/A C/A <<< <<< <<< <<<
I.C. engine oil
3-24 V V <<< <<< <<<
I.C. engine oil filter
3-24 R R <<< <<< <<<
Fuel pre-filter cartridge
3-25 R R <<< <<< <<<
Fuel filter cartridge
3-25 R R <<< <<< <<<
Fuel tank
3-28 N <<< <<<
Fuel tank breather
3-28 R <<< <<<
Safety dry air filter cartridge
3-28 R <<< <<<
I.C. engine silent blocks
C** <<< <<<
I.C. engine rates
C** <<< <<<
Valves clearances
C** C** <<< <<<
Cooling liquid
3-34 V <<<
Radiator
C** <<<
Water pump and the thermostat
C** <<<
Alternator and the starter motor
C** <<<
Turbocompressor
C** <<<
Fuel circuit
3-38 P
TRANSMISSION
Gear box oil level
3-13 C C <<< <<< <<< <<< <<< <<<
Transmission universal joint
3-18 G G <<< <<< <<< <<< G/C**
Gear box oil
3-29 V V <<< <<<
Gear box oil filter
3-29 R R <<< <<<
Silentblocks in the gear box
C** <<< <<<
Gear box controls
C** <<< <<<
Gear box pressures
C** <<<
Converter pressure
C** <<<
Wear of the brake pads and the brake disk
C**
TYRES
Tyres pressure
3-13 C C <<< <<< <<< <<< <<< <<<
Wheel nuts torque
3-13 C C <<< <<< <<< <<< <<< <<<
Condition of wheels and tyres
C** <<< <<<
Wheel
3-38 R
JIB
Jib pads
3-13 G* <<< <<< <<< <<< <<< <<<
Jib
3-18 G G <<< <<< <<< <<< <<<
Outer jib chains
MT 1840 E3
3-21 N/G/C N/G/C <<< <<< <<< <<<
Jib pads wear
C** <<< <<<
Outer jib chain wear
MT 1840 E3
3-30 C <<< <<<
Condition of jib unit
C** <<<
Bearings and articulation rings
C** <<<
Inner jib chain wear
MT 1840 E3
3-36 C
HYDRAULIC
Hydraulic oil level
3-17 C C <<< <<< <<< <<< <<<
Hydraulic return oil filter cartridge
3-26 R R <<< <<< <<<
Hydraulic oil
3-31 V <<< <<<
Breather for the hydraulic oil tank
3-31 R <<< <<<
Suction strainer for hydraulic oil tank
3-31 N <<< <<<
Brake accumulator unit filter
3-31 R <<< <<<
Speeds of hydraulic movements
C** <<< <<<
Hydraulic pump tubular filter
N** <<< <<<
Condition of hoses and flexibles pipes
C** <<< <<<
Condition of cylinders (leakage, shafts)
C** <<< <<<
Hydraulic circuit pressures
C** <<<
Hydraulic circuit outputs
C** <<<
Hydraulic oil tank
N** <<<
