Manitowoc 14000 Product Guide

Performance data
Model 14000
17
Wire Rope Lengths
Luffing Jib No. 135 on
Boom No. 76
Luffing Jib Hoist Line
Boom or
Boom and
Jib Length
Hoist Line
Drum 2
Maximum
Required
Parts of
Line
m (ft) m (ft)
20 (66) 244 (800) 4
23 (76) 259 (850) 4
26 (85) 274 (900) 4
29 (95) 290 (950) 4
32 (105) 305 (1000) 4
35 (115) 320 (1050) 4
38 (125) 320 (1050) 3
41 (135) 335 (1100) 3
44 (144) 351 (1150) 3
47 (154) 351 (1150) 3
50 (164) 351 (1150) 3
53 (174) 366 (1200) 3
56 (184) 366 (1200) 3
59 (194) 366 (1200) 3
NOTE: Hoist line lengths given in table include
all luffing jib lengths. Hoist line lengths given
in table will allow hook to touch ground. When
block travel below ground is required, add ad-
ditional rope equal to parts of line times added
travel distance. Hoisting distance or line pull
may be limited when block travel below ground
is required.
Wire Rope Specifications 5:1 Safety Factor
Boom No. 76
- or -
Fixed Jib No. 134 on Boom No. 76
5:1 Safety Factor
Rotation Resistant, 2 160 N/mm
2
Wire rope with Pad Eye
5:1 Safety Factor
Rotation Resistant, 2
160 N/mm
2
. Wire rope
Function Hoist Line Whip Line Auxiliary Line
Part Number No. 719432 No. 719432 No. 719436
Size Wire Rope 26 mm
—
26 mm
—
—
(1")
Minimum Breaking
Strength
71 940 kN
(158,600 lb)
71 940 kN
(158,600 lb)
69 760 kN
(153,800 lb)
Maximum Load
Per Line
14 290 kg
(31,500 lb)
14 290 kg
(31,500 lb)
9 070 kN
(20,000 lb)
Approximate Weight 3,56 kg/m
(2.39 lb/ft)
3,56 kg/m
(2.39 lb/ft)
3,36 kg/m
(2.26 lb/ft)
