Manitowoc 14000 Product Guide

Performance data
Model 14000
19
Maximum Length - Unassisted Raising
No. 135 Luffing Jib on No. 76 Main Boom Series 2
In-Line Method
No. 135 Luffing Jib
Jack-Knife Method
No. 135 Luffing Jib
Boom
Length
m (ft)
Over End
of Blocked
Crawlers
Over Side
Of
Crawlers
Over End
of Blocked
Crawlers
Over Side
Of
Crawlers
20,0
(66)
21,3 - 51,8
(70 - 170)
21,3 - 51,8
(70 - 170)
23,0
(76)
21,3 - 51,8
(70 - 170)
21,3 - 51,8
(70 - 170)
26,0
(85)
21,3 - 51,8
(70 - 170)
21,3 - 51,8
(70 - 170)
29,0
(95)
21,3 - 51,8
(70 - 170)
21,3 - 51,8
(70 - 170)
32,0
(105)
21,3 - 51,8
(70 - 170)
21,3 - 51,8
(70 - 170)
35,0
(115)
21,3 - 51,8
(70 - 170)
21,3 - 48,8
(70 - 160)
—
—
51,8
(170)
38,0
(125)
21,3 - 51,8
(70 - 170)
21,3 - 39,6
(70 - 130)
—
—
42,7 - 51,8
(140 - 170)
41,0
(134)
21,3 - 45,7
(70 - 150)
21,3 - 33,5
(70 - 110)
48,8 - 51,8
(160 - 170)
36,6 - 51,8
(120 - 170)
44,0
(144)
21,3 - 42,7
(70 - 140)
21,3 - 27,4
(70 - 90)
45,7 - 51,8
(150 - 170)
30,5 - 51,8
(100 - 170)
47,0
(154)
21,3 - 33,5
(70 - 110)
—
—
36,6 - 51,8
(120 - 170)
21,3 - 51,8
(70 - 170)
50,0
(164)
21,3 - 27,4
(70 - 90)
—
—
30,0 - 51,8
(100 - 170)
21,3 - 51,8
(70 - 170)
53,0
(174)
21,3 - 51,8
(70 - 170)
—
—
56,0
(184)
21,3 - 51,8
(70 - 170)
—
—
59,0#
(194)
21,3 - 51,8
(70 - 170)
—
—
NOTE: Load block(s), hook(s) and weight ball(s) on ground until boom
and luffing jib are erected. Boom lengths shown with a pound sign (#)
require lower boom point and wire rope guide assembly No. 177364 to
be removed.
