Part Number 000015432 Rev02 5/21 113
CNF0201 & CNF0202 With Evaporator Thermostat
Electrical Diagram
Number Component
1 Control board Line Voltage Connector
5 Compressor
7 Low Temperature Evaporator Thermostat
12 Compressor Start Capacitor
13 Compressor Start Relay
14 Condenser Fan Motor
17 Contactor Coil
18 Contactor Contacts
20 Dispense Switch
25 Fan Cycle Control
27 Float Switch - Water Level
29 Motor - Dispense
29-1 Motor - Evaporator
29-2 Motor - Evaporator Overload
30 Hall Effect Switch
31 High Pressure Cutout
36 Low Pressure Control
34 LED - HES1
34-1 LED - HES2
34-2 LED - Clean
34-3 LED - Water Level
34-4 LED - Blue Light
40 On/Off/Clean Switch
40-1 Ice
40-2 Off
40-3 Clean
41 See Control Board Schematic For Detail
47 Solenoid Valve - Water Dispense
51 Touchless Control Board
51-1 Touchless Control Board Wiring
52 Touchless Control Pad
52-1 Ice Only Selection
52-2 Water Only Selection
52-3 Water and Ice Selection
55 Water Dump Valve
Wire Colors
BLK Black
RED Red
WHT White
Refer to control board schematic for control board detail
To Next Page
