Part Number 000015432 Rev02 5/21 89
LOW TEMPERATURE THERMOSTAT
FUNCTION
Stops the ice machine if the evaporator temperature is
too low. The thermostat is closed at temperatures above
setpoint and opens at temperatures below setpoint.
Specifications
Cut-Out Cut-In
-25°C (-13°F) 4°C (25°F)
CHECK PROCEDURE
1. Attach and insulate a temperature meter
thermocouple next to the Low Temperature
thermocouple.
2. Disconnect wires from low temperature thermostat
and connect ohm meter across temperature control
terminals.
Replace the temperature control if it:
1. Is not closed at the specified setpoint.
2. Does not open at the specified setpoint.
Factory Setting Is Four
1
2
3
4
5
6
7
