Manitowoc CVDT1200 Technician's Handbook

Part Number: 000015431 Rev01 5/19 203
IF0600C/CVDF0600 IB0620C/CVDF0600
IBF0820/CVDF0900 IF0900C/CVDF0900
Number Component
1 Compressor
2 Discharge Check Valve
3 Condenser - Remote Air-Cooled
4 Head Pressure Control Valve
5 Liquid Line Shut-off Valve
6 Liquid Line Check Valve
7 Receiver
8 Receiver Access Valve
9 Liquid Line Filter Drier
10 Liquid Line Solenoid Valve
11 Heat Exchanger
12 TXV - Thermostatic Expansion Valve
13 Evaporator
14 Harvest Solenoid Valve
15 Suction Shut-off Valve
16 S Trap - Required on 21’ or greater rise
17 Suction line Filter
18 Accumulator
T1 Thermistor - Receiver Inlet
T2 Thermistor - Receiver Outlet
T3 Thermistor - Evaporator Inlet
T4 Thermistor - Evaporator Outlet

Manitowoc CVDT1200 Specifications

General

Brand	Manitowoc
Model	CVDT1200
Category	Ice Maker
Language	English
