Manitowoc Indigo ID0906A User Manual

Part Number STH025 11/16 259
I1400N
Remote Air-Cooled Condenser Model
Characteristics vary depending on operating conditions.
CYCLE TIMES
Freeze Time + Harvest Time = Total Cycle Time
Air Temp.
Entering
Condenser
°F/°C
Freeze Time
Harvest
Time
1
Water Temperature °F/°C
50/10 70/21 90/32
70/21 8.8-10.1 9.9-11.3 10.9-12.3
0.75-2.0
80/27 9.0-10.2 10.1-11.5 11.0-12.5
90/32 9.2-10.5 10.6-12.1 11.4-13.0
100/38 9.9-11.3 11.6-13.2 12.6-14.3
110/43 11.1-12.6 11.8-13.4 13.7-15.6
1 Times in minutes
24 HOUR ICE PRODUCTION
Air Temp. Entering
Condenser °F/°C
Water Temperature °F/°C
1
50/10 70/21 90/32
70/21 1430 1290 1200
80/27 1410 1270 1180
90/32 1380 1220 1140
100/38 1290 1130 1050
110/43 1175 1110 970
1 Based on average ice slab weight of 10.25- 11.50 lb.
OPERATING PRESSURES
Air Temp
Entering
Condenser
°F/°C
Freeze Cycle Harvest Cycle
Discharge
Pressure
PSIG
Suction
Pressure
PSIG
Discharge
Pressure
PSIG
Suction
Pressure
PSIG
1
50/10 210-240 38-24 100-160 70-85
70/21 240-265 40-26 110-170 70-90
80/27 250-275 45-28 110-180 70-95
90/32 250-290 48-29 110-180 70-95
100/38 275-335 51-31 110-185 75-100
110/43 310-375 55-32 120-190 80-110
1 Suction pressure drops gradually throughout the freeze cycle
