Part Number STH025 11/16 95
EXPORTING DATA TO A FLASH DRIVE
Data can be copied from the control board memory
to a flash drive and used to transfer setup and/or cycle
data to a replacement control board or to transfer setup
information to multiple ice machines. Data may also be
requested by service department personnel for analysis
or as an aid to troubleshooting. The data files are small
and can be attached to an email.
Important
The flash drive must be formatted before using,
Refer to page 95 USB Flash Drive Specifications and
Formatting. All files and data are deleted during the
formatting process.
1. Ensure that the ice machine’s power is on.
2. Press the Menu button.
3. Press the Down arrow until Service is highlighted.
4. Press the Checkmark. The Service menu will be
displayed.
USB Setup USB Stick Export All
5. Press the Down arrow until USB Setup is highlighted.
To Next Page
