MAINTENANCE CHECKLIST OPERATOR MANUAL NBT60XL
6-12 Published 11-01-2020 Control # 710-00
Camera (Optional)
Monitor (Crane Cab)
Input Voltage ......................................................................... 12 volts to 60 volts (±10%)
Size ....................................................................................... 17.78 cm (7 inches)
Resolution ............................................................................. WVGA 800 x RGB x 480 Pixels
Cameras (Hoist and Rear View)
Power Input ........................................................................... 12 to 24 V/DC
Video Signal .......................................................................... NTSC 720 (Hor) x 480 (Vert), 60 fields per second
View Angle (Hoist Camera) ................................................... 80° (Horizontal)
View Angle (Rear View Camera) ........................................... 170° (Horizontal)
General Specifications
Capacity NBT60XL/NTC60XL ............................................... 54.4 metric tons (60 tons) at 1.8 m (6 ft) radius
Overall Length ....................................................................... 12.6 m (41.42 ft)
Overall Width......................................................................... 2.6 m (101.6 in)
Overall Height........................................................................ 3.95 m (155.5 in)
Boom Length, 151 ft, 5 section .............................................. Retracted 11.3 m (37 ft), Extended 46.0 m (151 ft)
Jib Length (Telescoping 4-plate Construction........................ Retracted 7.9 m (26 ft), Extended 13.7 m (45 ft)
Jib Length (Fixed Length Lattice) .......................................... 11.1 m (36.5 ft)
Jib Offset (Telescoping) ......................................................... 0° and 30°
Jib Offset (Lattice) ................................................................. 0°, 15°, and 30°
Machine Weight (without Chassis/Jib) NBT60XL/NTC60XL . 25,038.3 kg (55,200 lb)
