Part Number 80-01111-9 7/10 197
Brazing Procedures for Danfoss
Solenoid Valves
• Danfoss stainless steel solenoid valves require a
slightly different brazing technique than brass-
bodied valves.
Copper clad stainless steel does not require as
much flame contact as copper tubing.
Apply heat to the copper tubing first then the
solenoid socket.
• 15% silver solder is recommended although silver
bearing solder in the 5% to 55% range can be
used.
1. Remove coil and verify direction of flow.
2. Fit valve in place and align stem at the 12:00
position.
3. Do not disassemble valve.
