152 Part Number 000015433_05 3/21


1 Compressor
2 Condenser (Air or Water-cooled)
3 Liquid Line Drier
4 Liquid Line Solenoid Valve
5 Suction Accumulator
6 Thermostatic Expansion Valve
7 Liquid Accumulator
8 Evaporator
1
2
3
4
5
6
7
8
