Manitowoc S model User Manual

Section 2 Installation Instructions
Part Number 000002477 3/08 2-13
Electrical Requirements
QuietQube® Ice Machine Head Section
Local or state electrical code, length of wire run or materials used, can increase the minimum wire or breaker
size requirement. A qualified electrician must determine the wire and breaker size, although the minimum
wire size must meet or exceed the specifications in these charts.
Important
Due to continuous improvements, this information is
for reference only. Please refer to the ice machine
serial number tag to verify electrical data. Serial tag
information overrides information listed on this page.
Ice Machine
Voltage
Phase
Cycle
Maximum
Fuse/Circuit
Breaker
Total Amps
**Minimum Wire Size
Required by Manitowoc
Minimum Breaker
Size Required by
Manitowoc
S0600C
115/1/60
230/1/50
15 amp
15 amp
1.1
0.6
#14 Solid Copper
Conductor
15 amp
15 amp
S0850C
115/1/60
230/1/50
15 amp
15 amp
1.1
1.5
#14 Solid Copper
Conductor
15 amp
15 amp
IB0620C
IB0820C
IB1020C
115/1/60
230/1/50
15 amp
15 amp
1.4
0.8
#14 Solid Copper
Conductor
15 amp
15 amp
S1000C
115/1/60
230/1/50
15 amp
15 amp
2.5
1.5
#14 Solid Copper
Conductor
15 amp
15 amp
S1200C
115/1/60
230/1/50
15 amp
15 amp
2.5
1.5
#14 Solid Copper
Conductor
15 amp
15 amp
S1470C
S1870C
S2170C
115/1/60
208-230/1/60
230/1/50*
15 amp
15 amp
15 amp
1.1
0.6
0.6
#14 Solid Copper
Conductor
15 amp
15 amp
15 amp
* Not available on S2170C models.
** All conductors must be solid copper wire
