Manitowoc URF0310A Technician's Handbook

Part Number 000014797 Rev02 05/18 237


Number Component
3 Bin Switch
5 Compressor
7 Compressor Overload
12 Compressor Start Capacitor
13 Compressor Start Relay
14 Condenser Fan Motor
17 Contactor Coil
18 Contactor Contacts
19 Control Board
25 Fan Cycle Control
26 Float Switch - Harvest
27 Float Switch-Water Level
28 Fuse
31 High Pressure Cutout
40 On/Off/Clean Switch
41 See Control Board Schematic For Detail
42 Solenoid Valve
49 Thermistor
55 Water Dump Valve
56 Water Inlet Valve
58 Water Pump
Wire Colors
BLK Black
BLU Blue
BRN Brown
PNK Pink
PRPL Purple
RED Red
WHT White
YEL Yellow
Refer to control board schematic for control board detail

Manitowoc URF0310A Specifications

General

Brand	Manitowoc
Model	URF0310A
Category	Ice Maker
Language	English
