80 Part Number 000014797 Rev02 05/18
Ice Making Sequence Of Operation Control Board Relays Length of Time
Compressor
2
Hot Gas Valve
Water Fill Valve
Water Pump
Fan Motor
Initial Start-up
1. Water Purge
2. Refrigeration Start-up
off on off
175 Seconds
(2.9 minutes)
on on off 5 Seconds
3. Freeze Cycle on off on Automatically Determined
4. Harvest cycle on on off Automatically Determined
5. Automatic Shut-off off off off Until Bin Thermostat Closes
To Next Page
