96 Part Number 000014797 Rev02 05/18
ICE MACHINE CYCLES INTO HARVEST BEFORE WATER
LOSES CONTACT WITH THE HARVEST FLOAT SWITCH
Step 1 Disconnect power to the ice machine, remove
the electrical panel to allow viewing of the control board
lights and pull the wire connector for the harvest float
switch through the bulkhead and disconnect.
WIRE CONNECTORS ARE LOCATED BEHIND BULKHEAD
PULL THROUGH GROMMET TO DISCONNECT
HARVEST FLOAT
SWITCH & BRACKET
ICE THICKNESS FLOAT
SWITCH & BRACKET
To Next Page
