Marshall Amplification Acton Bluetooth User Manual

020.
TECHNICAL INFORMATION
SOUND SPECIFICATION
• ACTIVE STEREO LOUDSPEAKER WITH BASS REFLEX SYSTEM
• DIGITAL CLASS D AMPLIFIER: 2X8W + 1X25W
• ¾” DOME TWEETERS: 2X
• 4” WOOFER: 1X
• BASS AND TREBLE TONE CONTROLS
• FREQUENCY RESPONSE: 50 - 20,000Hz +/-3dB
• CROSSOVER FREQUENCY: 2,500Hz
• CONNECTIVITY:
- BLUETOOTH: STANDARD V4.0
- INPUT - 3.5mm: 1X
• MAX POWER OUTPUT: 50W RMS
TECHNICAL INFORMATION
• MAINS INPUT VOLTAGE: 100-240V~ /200W
• NOMINAL RATING: 100-240V~
• ABSOLUTE MIN/MAX: 90-264V~
• MAINS FREQUENCY: 50-60Hz
• MAX PEAK POWER CONSUMPTION: 70W
• WEIGHT: 3.00kg
• SIZE: 265 X 160 X 150mm
NOTE: THE FRONT IS NOT REMOVABLE. THIS ILLUSTRATION INTENDS TO
SHOW THE INTERNAL SPEAKER LAYOUT. DO NOT ATTEMPT TO REMOVE
THE FRONT FRET FOR RISK OF DAMAGING YOUR SPEAKER.

Marshall Amplification Acton Bluetooth Specifications

General

Brand	Marshall Amplification
Model	Acton Bluetooth
Category	Speakers
Language	English
