028.
NOTE: THE FRONT IS
NOT REMOVABLE. THIS
ILLUSTRATION INTENDS TO
SHOW THE INTERNAL SPEAKER
LAYOUT. DO NOT ATTEMPT
TO REMOVE THE FRONT FRET
FOR RISK OF DAMAGING YOUR
ACTIVE LOUDSPEAKER.
TECHNICAL INFORMATION
*PLAYING TIME CALCULATED WITH THE STOCKWELL PLAYING AT VOLUME CONTROL 5 WITH RANDOMLY SELECTED MUSIC CONTENT.
SOUND SPECIFICATION
• ACTIVE STEREO LOUDSPEAKER WITH BASS REFLEX SYSTEM
• TONE CONTROLS:
- BASS: 300Hz, +6dB TO -12dB
- TREBLE: 3kHz, +6dB TO -12dB
• CLASS D AMPLIFIER: 2 X 10W
• WOOFER: 2 X 2.25”
• FULL RANGE: 2 X 2.25”
• PASSIVE RADIATORS: 2 X 3.5” X 1.5”
• MAX SPL: 90dB SPL @ 1m
• FREQUENCY RANGE: 50 - 20 000Hz
CONNECTIVITY
• BLUETOOTH: STANDARD V4.0 + EDR
• INPUT - 3.5mm STEREO PLUG
TECHNICAL INFORMATION
• POWER ADAPTER: 15V/1.8A
• MAX PEAK POWER CONSUMPTION: 60W
• STANDBY POWER CONSUMPTION:
- BATTERY MODE: 150μA
- POWER ADAPTER MODE: 0.2W
• USB CHARGING OUTPUT: 5V/1A
• AUDIO OUTPUT: 27W RMS
• BATTERY TYPE: 3 X 3.7V LI-IO BATTERIES, 2200mAh
• BATTERY PLAYING TIME:
- MAX VOLUME: 10h
- MID VOLUME: 25h
*
• BATTERY CHARGING TIME: 3h
• WEIGHT: 1.20kg
• SIZE: 260 X 140 X 41mm
