Dimensions
Dimensions Dimensions
Dimensions
Ref.
Inches
cm
A A
A
17.043.2
B B
B
46.4117.9
C C
C
39.099.1
D D
D
8.521.6
E E
E
22.857.9
F F
F
9.624.4
G G
G
14.937.8
H H
H
12.030.5
J J
J
10.225.9
K K
K
14.536.8
L L
L
11.930.2
12
3A6887A
