MasterCraft LASER DISTANCE FINDER/MEASURING TOOL User Manual

11
LASER DISTANCE FINDER/MEASURING TOOL - 057-4585-0
12
LASER DISTANCE FINDER/MEASURING TOOL - 057-4585-0
Turning the laser distance finder/measuring tool on and off
1. Press the power key
to turn on the tool.
2. The tool will automatically self-calibrate. During this process, the laser will turn on briefly.
WARNING!
Do not point the laser dot at persons or animals and do not stare into the laser beam
or view it directly with optical instruments.
3. The tool will default to the single-distance measuring mode, indicating that the tool is ready
to take measurements.
4. Press the power key
for about 2 seconds to turn off the tool.
5. When the laser distance finder/measuring tool is inactive for 5 minutes, it will automatically
turn off to save battery power.
To change measuring reference point
The default reference setting is from the rear of the tool. Press the measuring reference point
key
. Each time the key is pressed, the reference point will change: the rear of the tool,
the position of the tripod screw, the front of the tool or the positioning pin location; the next
measurement will be taken from the position you set.
After powering off, the reference point will automatically default back to rear of the tool.
Clear function
Push the clear key to erase the current measurement and display the previous
measurement.
While making area, volume or indirect measurements, each single measurement can be
deleted and re-measured in series. Continuously press the key to go back to single-distance
measurement mode.
To change the units
Press the
key to change the units among the choices listed below.
DISTANCE AREA VOLUME
0.000 m 0.000 m
2
0.000 m
3
0 mm 0.000 m
2
0.000 m
3
0.000 ft 0.000 ft
2
0.000 ft
3
0' 00"
1/16
0.000 ft
2
0.000 ft
3
0.0 In 0.000 ft
2
0.000 ft
3
0 In
1/16
0.000 ft
2
0.000 ft
3
To start the measurement
WARNING!
Do not point the laser dot at persons or animals and do not stare into the laser beam
or view it directly with optical instruments.
NOTE: The laser will switch off after 20 seconds of inactivity. If a measurement has not been
made within the previous 20 seconds, push measure key
again to turn on the laser.
Single distance measurement
1. Press the mode key
to choose the single-distance measurement mode. The mode icon
will blink on the LCD.
2. Press the measure key
to turn on the laser beam. Aim the laser at the target to which you
want to measure.
3. Press the measure key
again to take a measurement. The result is displayed immediately
on the LCD.
NOTE: After choosing Area, Volume or Pythagorean Theorem measurement modes, press the
clear key
to switch back to single-measurement mode.
OPERATING INSTRUCTIONS
OPERATING INSTRUCTIONS
