Warning Indica
tor
Warning
Code
Warning Event
Audible Alarm
Icon flashing
01
F
an
is
locked when inverter
is on.
Beep three tim
es every
second
02
Over temperature
None
03
Battery
is
over-charged
Beep once every se
cond
04
Low battery
Beep once every second
07
Overload
Beep once every 0.
5
second
10
Output power derating
Beep twice every 3 se
conds
15
PV energy is low.
Beep twice every 3 se
conds
16
High AC input (>280VAC) during
BUS soft start
None
32
Communication failure between
inverter and display panel
None
Battery equalization
None
42
44
