Matrix VS-S71 User Manual

8
ID
DESCRIPTION
QTY
1 M10 X 125L Socket Head Cap Screw 4
2 Wide Cupped Flange 3
3 User Frame 1
4 M10 Flat Washer 43
5 M10 Nylock Nut 12
6 Lower Connecting Tube 1
7 M10 X 20L Socket Head Cap Screw 14
8 Rear Connecting Tube 1
9 Rear Stack Support 1
10 M10 Flat Washer (Small Diameter) 4
11 M8 X 20L Socket Head Cap Screw 2
12 M8 Flat Washer 2
13 CAM Support Tube 1
14 M10 X 105L Socket Head Cap Screw 2
15 Narrow Cupped Flange 1
16 M10 X 120L Socket Head Cap Screw 1
17 Upper Connecting Tube 1
18 Exercise Arm 1
19 M10 Flat Washer (Ø42 mm) 1
20 Orange Pivot Indicator 1
21 M10 X 100L Socket Head Cap Screw 1
22 Axle 1
23 Ankle Pad and Weldment 1
24 Handlebar Assembly 1
25 M10 X 30L Socket Head Cap Screw 4
26 M10 X 25L Socket Head Cap Screw 6
27 Thigh Pad 1
28 Bottom Pad 1
29 Back Pad 1
30 Back Pad Mounting Tube 1
31 M10 X 75L Socket Head Cap Screw 2
32 M10 X 80L Socket Head Cap Screw 2
33 Back Pad Adjustment Tube 1
34 Front Shroud 1
35 Rear Shroud 1
36 Large M8 Flat Washer (Ø20 mm) 4
Parts List
