6
SECTION II
SPECIFICATIONS/COMPONENT IDENTIFICATION
A. SPECIFICATIONS
NOTE: Manufacturer reserves the right to make changes in specifications at any time without notice or
obligation.
GAS
Shaded areas are stated in metric equivalents 9/4/03
MAXIMUM CAPACITY (DRY WEIGHT) 120 lbs
54.4 kg
BASKET (TUMBLER) DIAMETER 44-1/2”
113 cm
BASKET (TUMBLER) DEPTH 42-1/2”
107.9 cm
BASKET (TUMBLER) MOTOR 3/4 hp
0.560 kW
BLOWER MOTOR 3 hp
2.238 kW
DOOR OPENING (DIAMETER) 31-3/8”
79.7 cm
BASKET (TUMBLER) VOLUME 38.2 cu ft
1.08 cu m
AIRFLOW 2,150 cfm
60.88 cmm
S.A.F.E. WATER CONNECTION 3/4-11.5 NH
VOLTAGE AVAILABLE 208-575v 3ø 3, 4w 50/60 Hz
APPROX. WEIGHT (UNCRATED) 1,349 lbs
611.9 kg
APPROX. WEIGHT (CRATED) 1,489 lbs
675.4 kg
HEAT INPUT 375,000 Btu/hr
94,500 kcal/hr
INLET SIZE 1-1/4” F.N.P.T.
To Next Page
