Warning/Indicator Lights
Warning/Indicator lights will appear in any of the highlighted areas
Signal Warning/Indicator Lights Page
Brake System Warning Light 4-17
Master Warning Light 4-18
Antilock Brake System (ABS) Warning Light 4-18
Charging System Warning Light 4-19
Engine Oil Pressure Warning Light 4-19
Check Engine Light 4-20
High Engine Coolant Temperature Warning Light (Red) 4-20
When Driving
Instrument Cluster and Display
4-15
CX-5_8CA5-EA-11L_Edition1 Page137
Monday, December 12 2011 11:30 AM
Form No.8CA5-EA-11L
