McQuay AGR 090AS Product Manual

Product Manual AGR-3 AGR 070A through 100A
23
Electrical Data
Table 15, 60 Hz, Single Point Power Electrical Data
POWER SUPPLY
Field Wire Conduit Hub
AGR
Unit
Size
Volts
Minimum
Circuit
Ampacity
(MCA)
Quantity
Wire
Gauge
Quantity
Nominal
Size
Max. Fuse
or
HACR Breaker
Size
208 322 3 400 1 2.50 450
230 300 3 350 1 2.50 400
380 190 3 3/0 1 2.00 250
460 153 3 2/0 1 1.50 200
070AS
070AM
575 114 3 #2 1 1.25 150
208 351 3 500 1 3.00 450
230 329 3 400 1 2.50 450
380 220 3 4/0 1 2.00 300
460 163 3 2/0 1 1.50 225
075AS
075AM
575 126 3 #1 1 1.50 150
208 384 6 3/0 2 2.00 500
230 373 3 500 1 3.00 500
380 240 3 250 1 2.50 300
460 187 3 3/0 1 2.00 250
080AS
080AM
575 151 3 2/0 1 1.50 200
208 411 6 4/0 2 2.00 500
230 408 6 4/0 2 2.00 500
380 256 3 300 1 2.50 350
460 206 3 4/0 1 2.00 250
085AS
085AM
575 171 3 3/0 1 2.00 225
208 411 6 4/0 2 2.00 500
230 408 6 4/0 2 2.00 500
380 256 3 300 1 2.50 350
460 206 3 4/0 1 2.00 250
090AS
090AM
575 171 3 3/0 1 2.00 225
208 461 6 250 2 2.00 600
230 458 6 4/0 2 2.00 600
380 269 3 300 1 2.50 350
460 220 3 4/0 1 2.00 300
095AS
095AM
575 176 3 3/0 1 2.00 225
208 501 6 250 2 2.00 700
230 498 6 250 2 2.00 700
380 279 3 300 1 2.50 350
460 231 3 250 1 2.00 300
100AS
100AM
575 180 3 3/0 1 2.00 250
All Electrical Data notes are on page 26.
