Section 4 - Maintenance
90-8M0113987 eng DECEMBER 2015 Page 77
7. Inspect the sterndrive ground plate for loose or broken connections.
a - Sterndrive‑to‑bell housing ground plate
8. Inspect the continuity washers under the hydraulic manifold block fasteners for a loose or faulty connection.
a - Continuity washers
9. Inspect the sterndrive U‑joint bellows ground clips and exhaust tube ground clip for loose or faulty connections.
Exhaust tube ground clip shown, U-joint bellows ground clips similar
a - Exhaust tube ground clip
MerCathode
If the boat is equipped with a MerCathode system, the system should be tested to ensure that it is providing adequate output to
protect the underwater metal parts on the boat. The test should be made where the boat is moored, using a Reference
Electrode and Test Meter.
Reference Electrode
91‑76675T 1
Senses and electrical current in the water when testing the MerCathode system. Use to check hull
potential.
