200/225 OPTIMAX DTS
Page 28 / 42 90-10234050
Switched 12V Accessory Connection
+
-
ob01495
PUR
RED
a
b
c
d
e
f
g
h
a - Battery
b - Fuse - 40 Amp
c - Power harness with 40 Amp fuse
d - Switched 12V
e - Complete kit
f - Terminal block
g - Accessory power relay
h - DTS Command Module harness
