MAINTENANCE
eng 93
Gearcase Lubrication
When adding or changing gearcase lubricant, visually check for
the presence of water in the lubricant. If water is present, it may
have settled to the bottom and will drain out prior to the lubricant,
or it may be mixed with the lubricant, giving it a milky colored
appearance. If water is noticed, have the gearcase checked by
your dealer. Water in the lubricant may result in premature
bearing failure or, in freezing temperatures, will turn to ice and
damage the gearcase.
Examine the drained gearcase lubricant for metal particles. A
small amount of metal particles indicates normal gear wear. An
excessive amount of metal filings or larger particles (chips) may
indicate abnormal gear wear and should be checked by an
authorized dealer.
DRAINING GEARCASE
1. Place outboard in a vertical operating position.
2.
Remove propeller. Refer to Propeller Replacement.
3. Place drain pan below outboard.
4. Remove vent plug and fill/drain plug and drain lubricant.
a - Vent plug
b - Fill/drain plug
GEARCASE LUBRICANT CAPACITY
Gearcases with 25.4 mm (1.0 in.) diameter propeller shaft
Right‑hand rotation ‑ 970 ml (32.8 fl oz)
Left‑hand rotation ‑ 900 ml (30.4 fl oz)
