Mercury 4 TwoStroke User Manual

1 - Air vent screw
2 - Fuel tank cap
3 - Tilt handle
4 - Upper motor cover
5 - Lower motor cover
6 - Water pump indicator port
7 - Tilt lever
8 - Steering friction adjustment screw
9 - Anode
10 - Anti‑ventilation plate
11 - Water inlet
12 - Propeller
13 - Starter handle
14 - Shift lever
15 - Throttle grip
16 - Choke knob
17 - Stop switch
18 - Fuel connector
19 - Clamp screw
20 - Clamp bracket
21 - Trim position pin
22 - Oil plug (upper)
23 - Oil plug (lower)
24 - Fuel tank
25 - Fuel pickup elbow
26 - Primer bulb
27 - Fuel tank cap
28 - Air vent screw
29 - Fuel connector
30 - Air vent screw
31 - Fuel valve
32 - Choke knob
33 - Stop switch
34 - Fuel connector
4/4.9/5 Specifications
Models
4C 4.9 5B‑D
Overall length 700 mm (27.6 in.)
Overall width 310 mm (12.2 in.)
GENERAL INFORMATION
eng 13

Mercury 4 TwoStroke Specifications

General

Brand	Mercury
Model	4 TwoStroke
Category	Outboard Motor
Language	English
