81
CD651
Drive Belts - D3.6L Engines
WARNING
Make sure engine is shut off and ignition key is removed before inspecting belts.
1 All drive belts must be periodically inspected for tension and condition (excessive wear, cracks, fraying, or
glazed surfaces).
A Alternator Belt/Water Circulating Pump Belt
B Power Steering Pump Belt
C Vacuum Pump Belt (If so equipped)
2 Check belt tension by depressing belt, with moderate hand pressure, at points shown. Belt should depress
3/16 inch (5 mm).
ALTERNATOR BELT
CAUTION
Avoid water entering boat. If seawater pump hoses are to be removed with boat in the water, seacock
(if so equipped) must be closed, or water inlet hose must be disconnected and plugged to prevent
water from flowing into boat.
3 Close seacock, if so equipped, or plug seawater inlet hose.
4 Remove seawater hoses at seawater pump. Remove power steering belt.
5 Loosen mounting bolt. Loosen nut and tensioning bolt. Pivot alternator until belt can be removed.
A Mounting bolt
B Tensioning bolt
6 Remove old belt and install new belt. Adjust belt tension by pivoting alternator. When tension is correct, retigh-
ten all fasteners securely.
7 Reinstall and adjust tension of power steering belt.
8 Reconnect seawater hoses to seawater pump. Tighten hose clamps securely.
9 Open seacock, if so equipped, or remove plug from seawater inlet hose and reconnect hose. Tighten hose
clamps securely.
POWER STEERING PUMP BELT
10Loosen mounting bolt. Pivot pump by loosening nut and turning tensioning bolt until belt can be removed.
A Mounting bolt
B Tensioning bolt
11 Remove old belt and install new belt. Pivot pump using tensioning bolt to adjust belt tension.
12When tension is correct, retighten all fasteners securely.
VACUUM PUMP BELT
13 Remove power steering belt.
14 Loosen the vacuum pump mounting and tensioning screws, behind the bracket.
15 Appropriately pry or move the vacuum pump to loosen belt. Remove old belt.
16 Install new vacuum pump belt and adjust tension. Torque mounting and tensioning screws to 15 lb-ft (21 Nm).
To Next Page
