Mercury Jet 40 User Manual

MAINTENANCE
51
ob01659
• Tiller handle - Lubricate through fitting.
ob01660
• Steering Cable - Rotate steering wheel to fully retract the steering cable end into the outboard tilt tube.
Lubricate through fitting.
!
WARNING
The end of the steering cable must be fully retracted into the outboard tilt tube before adding lubricant. Adding
lubricant to steering cable when fully extended could cause steering cable to become hydraulically locked. A
hydraulically locked steering cable will cause loss of steering control, possibly resulting in serious injury or death.
ob01661
a
b
a - Fitting b - Steering cable end
3. Lubricate the following with light weight oil
• Steering Link Rod Pivot Points - Lubricate pivot points.
ob01662
Checking Power Trim Fluid
1. Tilt outboard to the full up position and engage the tilt support lock.
ob00434
