GASOLINE ENGINE 8.1 S INBOARD MODELS
Page 37 of 58
Exhaust System
CAUTION
Avoid exhaust hose failure. Discharge water from exhaust elbow must flow around
entire inside diameter of hose to avoid causing hot spots which could eventually
result in burned-through exhaust hoses. Exhaust hoses and/or tubes must be cor-
rectly connected to exhaust elbows so that they do not restrict the flow of discharge
water from exhaust elbow.
1. Exhaust hoses/tubes should be secured at each connection with at least 2 hose clamps.
2. Tighten all exhaust hose and/or exhaust tube clamps securely.
77593
a
b
b
a
b
b
a-Exhaust Tubes
b-Clamps
