Note the number of the push pins
before removal.
2. Remove the insulator by carefully
prying out the push pins to gain
access to the bulb sockets.
3. Remove the bulb socket by
rotating it counterclockwise and
pulling it down from the lamp
assembly.
4. Carefully pull bulb straight out of
socket and push in new bulb.
5. To complete installation, follow
the removal procedure in reverse
order.
• TYPE B
For bulb replacement, see a dealer
or qualified technician.
Replacing high-mount brakelamp bulbs — Wagon only
1. Open liftgate.
2. Remove two screw covers, screws
and handle from liftgate.
3. Remove two screws and the lower
trim panel from the liftgate.
4. Remove the upper trim panel.
Maintenance and care
197
