Portable 4000 count digital multimeter
23
Range 4 kHz 40 kHz 400 kHz 4 MHz 40 MHz
Caliber 0.005 - 4kHz 0.03 - 40kHz 0.2 - 400kHz 0.002-0.4MHz 0.02 - 0.4MHz
Resolution 1 Hz 10 Hz 0.1 kHz 1 kHz 10 kHz
Accuracy 0.1 % R ± 3 D
Protection 600 Vrms
Sensitivity 200 mVrms 200 mVrms 1 Vrms 3 Vrms 3 Vrms
Frequency band : 5 Hz ... 500 kHz
4. G
ENERAL SPECIFICATIO
NS
• Mechanical features :
Dimensions : 170 x 80 x 35 mm
Weight (with battery) : 285 g
• Packing : Dimensions : 230 x 155 x 65 mm
Weight : 385 g
• Power supply : 1 battery 9 V (type 6LF22 or 6LR61)
Battery life : approx. 200 hours with battery 6LR61
“ BAT ” : battery discharge indicator
• Buzzer : continuous beep for the continuity test
intermittent beep each time the switch is operated
or keys are pressed, and for overload indication
Response time < 100 ms
• Climatic conditions :
Reference temprature : 23°C ± 5°C
Operating temperature : 0°C to 45°C
Use temperature : 0°C to 50°C
Storage Temperature : -20°C to 60°C
Relative humidity : use <
80 %
storage <
95 %
Protection rating : IP 40
• Safety : IEC 61010-1
Insulation : class 2
Pollution degree : 2
Indoor use
Altitude < 2000 m
CAT III, 600 V max. to earth
• EMC : complies EN 61326-1
5. A
CCESSO
RIES
5.1
Accessories delivered with the multimeter
1 set of test leads................................................................AG0475A
1 battery 9 V (6LF22) .............................................................AL0042
1 fuse 10 A, 50 kA, HBC....................................................... AT0084
1 fuse 0.63 A, 18 kA, HBC.................................................... AT0519
1 protective elastomer case.............................................HX0002 (∗)
1 user’s manual................................................................906129640
(
∗
) version “ multimeter in a blister ”, only.
5.2 Optional
Protective elastomer case.....................................................HX0002
