Metso Neles Quartz LIMIT SWITCH User Manual

7 QZ 70 en 15
5.4.2 Type 14
5.5 Valve Control Terminals (VCT)
5.5.1 Type 93
6 SPDT Switches
SPARE
NC
NC
NC
C
NO
C
NO
C
NO
SPARE
SPARE
SPARE
NC
NC
NC
C
NO
C
NO
C
NO
SPARE
SPARE
THIRD
SWITCH
SECOND
SWITCH
TOP
SWITCH
BOTTOM
SWITCH
FIFTH
SWITCH
FOURTH
SWITCH
TOP NO2
TOP NC2
BTM NC1
BTM C1
TOP SWITCH
BOTTOM SWITCH
TOP NO1
TOP NC1
BTM NO1
BTM C2
TOP C1
TOP C2
BTM NO2
BTM NC2
SPARE
SPARE
SPARE
Additional 3-Pole
Terminal Block
Provided in Unit
(Individual Elements Actuate
with Common Plunger)
(Individual Elements Actuate
with Common Plunger)
FB +
FB -
OUT1 +
OUT 1 -
OUT2 +
OUT2 -
SIM JMPR
* Piezo Valve
SIM JMPR
Piezo Valve*
Piezo Valve*
not supplied
with unit
