CHAPTER 4: QUICKFLY RIGGING
IMPORTANT SAFETY CONSIDERATIONS!
When installing Meyer Sound loudspeakers and subwoofers, the following precautions should always be observed:
• All Meyer Sound products must be used in accordance
with local, state, federal, and industry regulations. It is
the owner’s and user’s responsibility to evaluate the reli-
ability of any rigging method for their application. Rigging
should only be carried out by experienced professionals.
• Use mounting and rigging hardware that has been rated
to meet or exceed the weight being hung.
• Make sure to attach mounting hardware to the building’s
structural components (roof truss), and not just to the
wall surface.
• Make sure bolts and eyebolts are tightened securely.
Meyer Sound recommends using Loctite
®
on all
threaded fasteners.
• Inspect mounting and rigging hardware regularly. Imme-
diately replace any worn or damaged components.
LEOPARD RIGGING OPTIONS
Table 4 summarizes the available rigging options for LEOPARD. For complete information about rigging hardware, including
dimensions, weight, configuration, and load ratings, refer to the MG-LEOPARD/900 Assembly Guide (PN 05.243.080.01)
available at www.meyersound.com
.
NOTE: The MCF-LEOPARD caster frame does not include quick-release pins because it is secured with the
quick-release pins included with the loudspeaker. The MG-LEOPARD/900 grid tilt kit does not include quick-
release pins because the angle feet are secured with the quick-release pins included with the grid.
Table 4: LEOPARD Rigging Options
Model Weight Features Required Quick-Release Pins Required
Shackles
MG-LEOPARD/900
multipurpose grid
(PN 40.243.080.01)
60.5 lb
(27.5 kg)
With some restrictions, flies up to 23 LEOPARDs at a 5:1
safety factor, or up to 20 LEOPARDs at a 7:1 safety
factor; supports mixed arrays of LEOPARDs and
900-LFCs without transition hardware; accommodates a
variety of pickup configurations with four corner and 13
center pickup points; includes attachment points to
accommodate brackets and adapters for lasers and
inclinometers; can also be used for groundstacking
5/16 x 0.875-inch (red button),
PN 134.025, qty 10 included
5/8-inch or
3/4-inch
MG-LEOPARD/900
grid tilt kit
(PN 40.243.163.01)
2lb
(0.9 kg)
Includes two angle feet that attach to the rear of the
MG-LEOPARD/900 grid that add from 3-8 degrees of tilt
to groundstacks
5/16 x 0.875-inch (red button),
PN 134.025, qty 0 included
—
MVP motor Vee plate
(PN 40.215.184.01)
20 lb
(9.1 kg)
Fine tunes the horizontal aim of arrays; compatible with
MTG-LEO-M, MTG-LYON, MTG-1100, and
MG-LEOPARD/900 grids
— 3/4-inch or
7/8-inch
MTF-LYON/LEOPARD
transition frame
(PN 40.232.140.01)
71 lbs
(32.2 kg)
With some restrictions, flies up to eight LEOPARDs at a
7:1 safety factor below LYON arrays for downfill; includes
rear attachment points for pull-back; collapsible for easy
transport on top of LEOPARD stacks
7/16 x 0.90-inch (black button),
PN 134.050, qty 0 included
1/2-inch or
5/8-inch
5/16 x 0.875-inch, red button,
PN 134.025, qty 8 included
PBF-LEOPARD
pull-back frame
(PN 40.243.185.01)
4.9 lb
(2.2 kg)
Attaches to bottom of LEOPARD and 900-LFC arrays (to
the bottom cabinet) and provides pull-back for extreme
array downtilt; can also be used to add tilt to LEOPARDs
groundstacked on the 900-LFC
5/16 x 0.63-inch (black button),
PN 134.024, qty 2 included
1/2-inch
MCF-LEOPARD
caster frame
(PN 40.243.130.01)
37 lbs
(16.8 kg)
Safely transports up to four LEOPARD cabinets, making
it easy to assemble and disassemble arrays in blocks of
four cabinets
5/16 x 0.63-inch (black button),
PN 134.024, qty 0 included
—
