OPERATING INSTRUCTIONS
8. Connecting pipe
9. Connecting cable
10. Stop valve
Outdoor unit
NOTE: The actual shape of the indoor unit
you purchased may be slight different
on front panel and display window.
NOTE:
All the pictures in this manual are for
explanation purposes only. Your air conditioner
may be slightly different. The actual shape
shall prevail.
Air inlet( rear)
Air inlet (side)
Air outlet
1. Front panel
2. Air inlet
3. Air filter
4. Air outlet
5. Horizontal air flow grille
6. Vertical air flow louver(inside)
7. Display panel
Indoor unit
VLED Display Window
RUN indication lamp
This lamp illuminates when the air
conditioner is in operation.
TIMER indication lamp
Lights up during Timer operation.
ION indication lamp(optional)
Lights up when Clean Air feature is activated.
DEFROST i
ndication lamp
(Enabled on cooling & heating models only):
Lights up when the air conditioner starts
defrosting automatically or when the warm
air control feature is activated in heating
operation.
4
3
5
2
6
1
9
10
8
7
Model Name And Dimensions
MODEL
WIDTH (mm)
HEIGHT (mm) DEPTH (mm)
9000 Btu
12000 Btu
18000 Btu
255
255
275
180
188
198
680
770
905
24000 Btu
1030
315
220
ion defrost run timer
(A) Display for D-3 Models
(B) Display for D-1 Models
(C) Display for D-6 Models
Signal Receiver
Signal Receiver
defrost run timer
3
