Midea Aqua thermal Super Series User Manual

Aqua thermal Super
21
Part 3 - Control
5 Normal Operation Control
5.1 Component Control during heating mode
Component
Wiring
diagram
label
65/75kW
110/140kW
Control functions and states
Water pump
PUMP
●
●
Open
Inverter compressor
1
BP1
●
●
Control the outlet water temperature. The operating
increased and decreased frequency is 1Hz/s.
Inverter compressor
2
BP2
●
●
Inverter fan1
FAN1
●
●
Startup after 4-way valve changes refrigerant flow direction.
Controlled according to ambient temperature, discharge
pressure and compressor frequency.
Inverter fan 2
FAN2
●
●
Electronic expansion
valve
EXV-A
●
●
Step from 0 to 480. Controlled according to discharge
temperature superheat.
Electronic expansion
valve
EXV-B
●
●
Step 480.
Electronic expansion
valve
EXV-C
●
●
Enhanced vapor injection EXV ， Step from 0 to 480.
Controlled according to temperature difference between
economizer plate heat exchanger inlet and outlet.
Four-way valve
ST1
●
●
Open
S valveolenoid
(defrost)
SV5
●
●
Open during defrost and close at other times.
S (byvalveolenoid
pass)
SV6
●
●
Closed
valveSolenoid
(injection)
SV8A/B
●
●
Open
Switching of
heating/hot water
production
Solenoid three way
valve
SV1
●
●
Turn on when making hot water
Component
diagramWiring
label
65/75kW
110/140kW
Control functions and states
Water pump
PUMP
●
●
Open
Inverter compressor 1
BP1
●
●
Control the outlet water temperature. The
operating increased and decreased frequency
is 1Hz/s.
Inverter compressor 2
BP2
●
●
Inverter fan1
FAN1
●
●
Control according to the exhaust pressure of
the outdoor unit. Correct every 20-60s, and
adjust in 0-32 gears.
Inverter fan 2
FAN2
●
●
E expansionlectronic
valve
EXV-A
●
●
Step 480.
E expansionlectronic
valve
EXV-B
●
●
Step from 0 to 480. Controlled according to
discharge temperature superheat.
MBT Confidential
5.2 Component control during cooling mode
