Midea Aqua thermal Super Service Manual
1 Electric Control Box Layout
For MH-SU65-RN8L and MH-SU75-RN8L
Main control board
Inductor
Fan module board (Fan B)
Expanding board
AC filter board
PED board
Main power supply wiring set
Module components (Compressor + Fan A)
For MH-SU110-RN8L and MH-SU140-RN8L
Main control board
AC filter board A
Inductor A Inductor B
AC filter board B
Expanding board
PED board A
PED board B
Main power supply wiring set
Module components A and B (Compressor + Fan )
MBT Confidential
