INSTALLATION
11
Wall
Slide bushing
1:Connection between ordinary tap and inlet hose.
2:Connection between screw tap and inlet hose.
• To prevent leakage or water damage, follow the instructions
Do not kink, crush, modify or cut the .
above-mentioned !
• water inlet hose
Warning!
Selection of tap
Please select
tap.
appropriate
Connection of inlet hose, tap and washing machine
clamp nut
tap
1.Loosen clamp nut
to show 5mm groove
2.Loosen four
screws
3.Set connecting base
on tap and tighten
evenly screws
4.Tighten clamp nut
inlet valve
inlet hose
slide bushing
5.Press slide bushing,
insert inlet hose into
connecting base
6. onnection nishedC 7.After connection and installation,
check if there is water leakage
tap with threads and inlet hose
special tap for washing machin
e
Screw tap
Special washing
machine tap
Ordinary tap
5mm
