Light Commercial R410A on-off DM17-01.01.08en
107
2. Specification
Indoor MFM-24ARN1-Q
Outdoor MOCA30U-24HN1-Q
Power supply V,Hz,Ph 220~240V,50Hz,1Ph
Cooling
Capacity Btu/h 24000
Input W 2500
Rated current A 12,07
EER W/W 2,81
Heating
Capacity Btu/h 26000+7000
Input W 2300+2300
Rated current A 11.11+10
COP W/W
3,31
Max. input consumption W 3450+2300
Max. current A 18+10
Starting current A 59,0
Compressor
Model PA291X3CS-4MTM1
Type ROTARY
Brand GMCC
Capacity Btu/h 24498/24669
Input W 2395/2540
Rated current(RLA) A 11.55/12.25
Locked rotor Amp(LRA) A 59
Thermal protector --
Thermal protector position INTERNAL
Capacitor uF 60UF/450V
Refrigerant oil/oil charge ml ESTER OIL VG74 · 950
Indoor fan motor
Model
YKT-75-8-1-1
Old Model YDK75-8
Input W 166/145
Capacitor uF 5
Speed(Hi/Mi/Lo)or (Hi/Lo) r/min 540/440
Indoor coil
a.Number of rows 2
b.Tube pitch(a)x row pitch(b) mm 21x13.37
c.Fin spacing mm 1.3
d.Fin type (code) Hydrophilic aluminium
e.Tube outside dia.and type mm Φ7,innergroovetube
f.Coil length x height x width mm 405x735x26.74
g.Number of circuits 6
Indoor air flow (Hi/Mi/Lo) or (Hi/Lo) m
/h 1154/1077
Indoor noise level (Hi/Mi/Lo)or (Hi/Lo) dB(A) 48.6/42.9
Indoor unit
Dimension(W*D*H) mm 500x315x1700
Packing (W*D*H) mm
1805x615x425
Net/Gross weight Kg 38.6/50.5
Outdoor fan motor
Model
YKT-75-6-200L
Input W 144
Capacitor uF 3UF/450V
Speed r/min 860
Outdoor coil
a.Number of rows
2
b.Tube pitch(a)x row pitch(b) mm 21x13.37
c.Fin spacing mm 1.2
d.Fin type (code) Hydrophilic aluminium
e.Tube outside dia.and type mm Φ7,innergroove tube
f.Coil length x height x width mm 730x651x26.74
g.Number of circuits 6
Outdoor noise level dB(A) 61.1
Outdoor unit
Dimension(W*D*H) mm 845x363x702
Packing (W*D*H) mm 965x395x755
Net/Gross weight Kg 52.7/56.1
Refrigerant type g R410A/1800
Design pressure MPa 4.2/1.5
Refrigerant piping
Liquid side/ Gas side
mm(inch) Φ9.52Φ15.9(3/8"/5/8")
Max. refrigerant pipe length m 25
