DM17-01.01.08en Light Commercial R410A on-off
66
1.
Features
1.1 High static pressure design
Max static pressure of indoor unit is 160Pa.
The longest distance of air supply is 14m, the max height of air supply is 6.5m.
Specially recommended for spacious and large rooms like large stores and factories.
1.2 Easy maintenance
The unit can be opened from top or bottom.
The air outlet flange is isolated from either top panel or base panel, which makes the maintenance
much easier when connecting duct.
1.3 Flexible Installation
Different solutions for any shape room by using kinds of air distribution ducts.
High static pressure design enables long duct.
Outlet
The height of air
supply is 6.5m
Max. 14m long distance
Indoor Unit
Fresh
Air Intake
Intake
L-sha
To Next Page
