1. Specification
Model MGC-F05W/N1 MGC-F07W/N1
Power supply V-Ph-Hz
220-240, 1, 50 220-240, 1, 50
Capacity kW 5 7.2
Cooling
Input W 1938 2755
Capacity kW 5.5 7.7
Heating
Input W 1987 2834
Max. input consumption W 2350 3200
Max. input current A 11.7 16.7
Starting current A 36.8 55
Model PA225X2CS-4KU1 PA330X3CS-4MU1
Type ROTARY ROTARY
Brand Midea-Toshiba Midea-Toshiba
Capacity Btu/h 18493 27807.8
Input W 1855 2760
Rated current (RLA) A 8.7 13.1
Locked rotor Amp (LRA) A 36.8 63
Thermal protector
Inner Inner
Capacitor uF 50uF/440V-450V 55uF/450V
Compressor
Refrigerant oil ml ESTER OIL VG74, 750 ESTER OIL VG74, 1100
Model YDK120-8U YDK120-8U
Type
AC motor AC motor
Brand
Welling Welling
Input (Hi/Lo) W 220 220
Capacitor uF 6uF/450V 6uF/450V
Outdoor fan
motor
Speed (Hi/Lo) r/min 660 660
Number of rows 1 1
Tube pitch(a)× row pitch(b) mm
22×19.05 22×19.05
Fin spacing mm 1.6 1.6
Fin type Hydrophilic aluminium foil Hydrophilic aluminium foil
φ7.94 φ7.94
Tube outside dia. and type mm
Inner grooved copper tube Inner grooved copper tube
Coil length ×height × width mm 893×880 893×880
Outdoor coil
Number of circuits 4 7
Type RS15/6-3-WILO RS15/6-3-WILO
Input (H/M/L) W 93/67/46 93/67/46
Water pump
Outdoor air flow m
3
/h 5563 5624
Throttle Capillary Capillary
Outdoor noise level (sound pressure) dB(A) 55 56
Water flow volume m
3
/h 0.86 1.24
The plate heat-exchanger water pressure drop kpa 21 35
The Max. and Min. water inlet pressure kpa
500/150 500/150
Dimension (W×H×D) mm 990×966×354 990×966×354
Packing (W×H×D) mm 1120×1100×435 1120×1100×435
Outdoor unit
Net/ Gross weight kg 83/89 94/100
Type R410A R410A
Refrigerant
type/Quantity
Charged volume g 1600 2100
Power wiring mm
2
3×2.5 3×2.5
Connection
wiring
Signal wiring (connect to wired
control)
mm
2
3×1.0 3×1.0
Pipe diameter Water inlet/outlet mm R1 R1
Control Wired controller Wired controller
Ambient temp． ℃
Cooling: 10℃~43℃; Heating: -15-24℃
Nominal capacity is based on the following conditions:
1. Condenser air in 35℃. Evaporator water in/out 12/7℃
2. Evaporator air in 7℃ 85% R.H., Condenser water in/out 40/45℃
3. The two types of oil are equivalents
4. At 1m in open field fan side (sound pressure)
5. The maximum and minimum operating pressure values refer to the activation of the pressure switches
