MCAC-UTSM-201606 Midea 50Hz AC Fan Coil Unit Two-pipe Wall-mounted Series
- 32 -
 A place which provides the space around the indoor unit as required right in the diagram.
 There is strong electromagnetic wave existing.
 A place which is far from heat, steam and inflammable gas.
13.4.2 Drilling A Hole and Mounting Installation Board
Installation Board and Its Direction (unit: mm)
250\300\400 type 500\600 type
 Fix the installation board
• Install the installation board horizontally on structural parts on the wall with the spaces provided around the
plate.
• In case of brick, concrete or similar type walls, make 5mm dia. holes on the wall. Insert clip anchors for
appropriate mounting screws.
• Fix the installation board on the wall.
Right installation
False installation
 Drilling a hole
• Determine the pipe hole position using the installation board, and drill the pipe hole (N95mm) so it slants
slightly downward.
• Always use a wall hole conduit when piercing metal lath, ply wood or metal plate.
13.4.3 Connective Pipe and Drainage Installation
 Drainage
Run the drain hose sloping downward. Do not install the drain hose as illustrated below.
460
25
290
915
m
o
u
n
t
i
n
g
b
o
a
r
d
o
f
i
n
d
o
o
r
unit
the
s
ha
p
e of indoor unit
73
0
3
1
6
1070
3
6
mounting board of indoor unit
the shape of indoor unit
