Midea MKH3-700R3 User Manual

Midea AC Fan Coil Unit
54
the heat exchanger out.
h) Pull out the temperature sensor plug.
Install back the heat exchanger in reverse order
Figure 10.5.3 Removal of casing
Figure 10.5.4 Removing the electric control box
Figure 10.5.5 Removal of drain pan and heat exchanger
2
2
1
1
Casing
assembly
Electric
control
box
1
1
2
2
2
2
1
1
1
1
1
1
1
Heat
exchanger
Temperature
sensor plug
Drain pan

Midea MKH3-700R3 Specifications
