Midea MP05DRWBA3RCM User Manual


Page 15

Installation
Instructions
Step Three: Preparing the Adjustable Window Slider
1. Choose the window sliders according the size of
your window. Sometimes, it needs to be cut short
to meet the window size, please take extra care to
cut it properly.
2. Use bolts to fasten the window sliders once they
are adjusted to the Proper length.
Window slider A Window slider B
Bolt
Window slider A Window slider B
Window slider C
Bolts
Step Two: Install the Exhaust hose assembly to the unit
Push the Exhaust hose into the airoutlet opening of
the unit along the arrow direction.
MODEL A
MODEL B MODEL C
1+2：
Bolt
Bolt
Bolt
1+2+3：
1+2：
1+2+3：
Bolt
Bolt
Bolt
1+2+3+4：
Bolt
BoltBolt
1+4：
Bolt
Window Sliders
After assembly
Before assembly
Window Sliders
After assembly
Before assembly
or
Window Installation Kit
Press the exhaust hose(or extended exhaust hose)
into the window slider adaptor(or wall exhaust
adaptor) and unit adaptor, clamp automatically by
elastic buckles of the adaptors.
Step One: Preparing the Exhaust Hose assembly
Unit adaptor
Window slider
adaptor
Exhaust hose
Exhaust hose
assembly
Exhaust hose
Extended Exhaust
hose
Exhaust hose assembly
Model D
Type window installation:
Model C
Model A Model B
Window slider
adaptor
Exhaust hose
assembly
Exhaust hose
Air exhaust
passage
Unit adaptor
Exhaust hose
assembly
Exhaust hose
Unit adaptor
Air exhaust
passage
Exhaust hose
assembly
Unit adaptor Wall exhaust
adaptor A
Exhaust hose
Exhaust hose
Extended Exhaust
hose
Exhaust hose assembly
Type wall installation:
Model A Model B
