Midea VRF V4 Plus I Series User Manual

R410A DC Inverter V4 Plus 50Hz MCAC-VTSM-2014-04
84 Troubleshooting
NO.
Content
1.1
Power transformer
1.2
Terminal block
1.3
Transformer
1.4
Outdoor main control board ass’y
1.5
Thermal resistance
1.6
Filter board
1.7
Main control box ass’y
1.8
Reactance
1.9
Cement type resistor
1.10
Contactor
1.11
Current detection board ass'y
1.12
Inverter module radiator ass’y
1.12.1
Three phase bridge
1.12.2
50A1200V inverter module
1.12.3
Power drive fitting board ass’y
1.13
Aluminum electrolytic capacitors
1.14
Capacitor
2.1
Outdoor fan driver board ass’y
2.2
Wire joint
2.3
Capacitor
2.4
Contactor
2.5
Electric box ass'y
