Front view
a Base
b Indicator lights
Left:
Powder detergent dispensing is
activated
Middle:
In-operation indicator
Right:
Liquid detergent dispensing is
activated
c Powder detergent container
d Liquid detergent container
Rear view
a Suds solution drainage connection
(detergent dissolved in water)
b Connection cable with plug
connector (socket for the plug
connector is located at the rear of
the washing machine)
c Water inlet connection
Components supplied
The following are supplied:
–
Dispensing unit base
–
Container for powder detergent
–
Container for liquid detergent
–
Two hoses for intake and drainage
–
Positioning guide
–
Bag containing screws (6 screws for
securing the hoses and 2 screws for
securing the positioning guide)
